Product Summary

The TTL hex inverter buffer/driver SN7406DR feature high-voltage open-collector outputs for interfacing with high-level circuits (such as MOS) or for driving high-current loads (such as lamps or relays), and also are characterized for use as inverter buffers for driving TTL inputs. The SN7406DR has minimum breakdown voltages of 30V. The maximum sink current is 40 mA for the SN7406DR.

Parametrics

SN7406DR absolute maximum ratings: (1)Supply voltage, VCC: 7V; (2)Input voltage, VI: 5.5V; (3)Output voltage, VO: 30V; (4)Package thermal impedance, θJA: D package, 86℃/W; N package, 80℃/W; NS package, 76℃/W; (5)Storage temperature range, Tstg: –65℃ to 150℃.

Features

SN7406DR features: (1)Convert TTL Voltage Levels to MOS Levels; (2)High Sink-Current Capability; (3)Input Clamping Diodes Simplify System Design; (4)Open-Collector Drivers for Indicator Lamps and Relays; (5)Inputs Fully Compatible With Most TTL Circuits.

Diagrams

SN7406DR schematic

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
SN7406DR
SN7406DR
Texas Instruments
Buffers & Line Drivers Hex Inv w/HV Output
Data Sheet
0-1: $0.50
1-25: $0.46
25-100: $0.39
100-250: $0.34
SN7406DRG4
SN7406DRG4
Texas Instruments
Buffers & Line Drivers Hex inverter Buffer/ Driver
Data Sheet
0-1700: $0.22
1700-2000: $0.20
2000-2500: $0.20
2500-5000: $0.19
SN7406DRE4
SN7406DRE4
Texas Instruments
Buffers & Line Drivers Hex inverter Buffer/ Driver
Data Sheet
0-1700: $0.22
1700-2000: $0.20
2000-2500: $0.20
2500-5000: $0.19
